Impinj M4 UHF RFID Small Inlay

Add to wishlistAdded to wishlistRemoved from wishlist 0

Enquiry

This UHF RFID Inlay is very small, and its diameter is only 12mm. With the Impinj M4 chip, it is very powerful. Impinj M4 inlay has higher read reliability, 66% higher than other chips. Also, it features high security, excellent RF performance, and good flexibility.,

FEATURES

This RFID inlay adopts the Impinj M4 chip. And it has excellent RF performance, higher read reliability, and good confidentiality. The detail characteristics of the Impinj M4 chip as follows:

  • True3D™ antenna technology—patented, dual-differential antenna ports enable compact Omni-directional tags, improving item-level read reliability
  • QT™ technology—protects business-sensitive data while assuring consumers of privacy
  • Available memory options to support large user-memory applications
  • BlockPermalock Gen2 command adds flexibility in memory usage
  • FastID™ mode enables 2x to 3x faster EPC+TID inventory for authentication and other TID-based applications
  • TagFocus™ mode suppresses previously read tags to enable capture of more tags
  • Extended temperature range (-40 ℃ ~ +85 ℃) for performance under hard conditions
  • Impinj’s field-rewritable NVM (optimized for RFID) provides 100,000-cycle/50-year retention reliability
  • EPCglobal and ISO 18000-63 compliant, Gen2V2 compliant

APPLICATIONS

    • Logistics tracking
    • Asset Management
    • Supply chain Management
    • Parking Management
    • Warehouse Management
    • Retail Management
    • Luggage management
    • Personal experience and safety
    • Important document management
    • Other Applications
%E5%BA%94%E7%94%A8 2%E5%BA%94%E7%94%A8 2
Impinj M4 UHF RFID Small Inlay 9

AVAILABLE OPTIONS

Available Shape Antenna model Size Chip
%E5%B0%BA%E5%AF%B82

%E5%B0%BA%E5%AF%B82

J41 φ12mm Impinj Monza 4
%E5%B0%BA%E5%AF%B83

%E5%B0%BA%E5%AF%B83

J42 15*8mm Impinj Monza 4
%E5%B0%BA%E5%AF%B81

%E5%B0%BA%E5%AF%B81

J51 φ12mm Impinj Monza 5

,

Parameters

Item Impinj Monza 4 UHF RFID Mini Inlay
Chip Impinj Monza 4
Frequency UHF 860-960MHz
Protocol ISO18000-6B/ISO 18000-6C EPC C1G2
Antenna Material Aluminum
Size Dia12 mm or Customized
Material Coated paper, Glossy paper, Matte paper
Reading distance 0-10cm
Write Endurance 100000 times
Working Temperature -25–65℃
Data Retention Time 10 years
Printing Options Silk-screen printing, Laser Engraving, CMYK full color, Pantone, etc.
Crafts Available Logo or number printing, Bar code, QR code, etc.
Samples Free samples are available upon request
